| Company Name | Shanghai Gokai Industry Co., Ltd. | ||||||||||||||||||||||||||||||||||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Image | |||||||||||||||||||||||||||||||||||||||||||||||
| About Us | Shanghai Gokai Industry Co., Ltd. is specialized in researching, developing, manufacturing and distributing PVC foam board, PVC rigid sheet, Aluminum sheet, acrylic sheet. The Company was founded in 2009, has set up factory in Shaoxing, Introduced advanced production equipment and processing technology. The world-leading equipment and rich experience with this process and this material have enable Gokai to create the PVC foam board, acrylic sheet, Aluminum sheet and PVC rigid sheet. That is perfectly matched to the requirements of the market. PVC Foam Board: We offer Advertising PVC foam board, Building Materials PVC foam board, Furniture PVC foam board. Thickness 1mm to 50mm. Our products are widely used in furniture, advertising, building materials, decoration and industrial appolcations and other fields. PVC Rigid Sheet: The sheet more than 7 kinds of color we can offer. Thickness 1mm to 6mm is available. It can be used in many fields such as: Sign board, display, pop-up display, exhibition board, screen printing, digital printing, computer lettering and marking boards, partitions, wallboard, indoor or outdoor decoration, ceiolng, commercial decorating shelves, dustless room board, olding boards, seashore dampproof equipment, art design materials, credit card, phone card, stationery, refrigeratory board, environmental protection plate. Aluminum Composite Panel: High-grade panel for both indoor and outdoor use. No lead no formaldehyde, it is environmental. Good resistance, easy installation, durable material, silencing material make this ACP panel popular. Thickness 2 mm to 6 mm. Any other customers′ requirements are negotiable. Acrylic Sheet: We offer Cast acrylic sheet and Extrude acrylic sheet, Widely used in advertising, sculpture, decorative and also in the tub, the bathroom. Thickness 1-500mm. Advanced manufacturing processes ensure acrylic sheet has excellent stiffness, strength and superior chemical resistance. | ||||||||||||||||||||||||||||||||||||||||||||||
| Tel | Login to view | ||||||||||||||||||||||||||||||||||||||||||||||
| Fax | Not set | ||||||||||||||||||||||||||||||||||||||||||||||
| Name | Mr. Jason Gokai | ||||||||||||||||||||||||||||||||||||||||||||||
| Address | Room 1003, Building 1, Lane 111, Luxiang Road, Baoshan District | ||||||||||||||||||||||||||||||||||||||||||||||
| Not set | |||||||||||||||||||||||||||||||||||||||||||||||
| Products Details |
PRODUCT PARAMETERS Cast Acrylic Sheet |
Product | Cast Acrylic Sheet |
Density | 1.2g/cm3 |
Thickness | 1.8-30mm |
Size | 1220*1830mm, 1250*1850mm, 1020*2020mm, 1220*2440mm, 2000*3000mm ,1550*3050mm,2050*3050mm etc |
Color | clear, transparent, marble, frosted, mirror, red, blue, white, black, more than 100 kinds of colors. No fading colour in outdoor at least 8-10 years |
Material | adopt the pure LUCITE, 100% virgin raw MMA |
Technology | cast acrylic sheet production process |
Quality | Our cast acrylic sheets conform to CE/SGS certificastes |
payment | L/C, T/T, Western Union, MoneyGram, Paypal |
Delivery | 10-15days after confirm your order |
Technical Data
Specific Gravity | 1.19-1.20 |
Rockwell Hardness | M-100 |
Shear Strength | 630Kg/cm2 |
Tensile Strength | 760Kg/cm2 |
Yield Strength | 1260Kg/cm2 |
Rupture Strength | 1050Kg/cm2 |
Light Transmittance | 94% |
Refractive Index | 1.49 |
Heat Distortion Temperature | 100ºC |
Thermal Forming Temperature | 140ºC-180ºC |
Coefficient of linear Thermal Expansion | 6×10-5cm/cm/ºC |
Dielectric Strength | 20Kv/mm |
Water(24HRS)Absorption | 0.30% |
FEATURES AND ADVANTAGES
• Optimally designed for digital printing
• Bright white, smooth and uniform surface
• Available in a wide range of standard and special designer colors
• Standard matt or gloss finishes
• Good insulation, lower heat transmission
• Non-toxic
• Flammability: self- extinguishing
• Easily worked with conventional tools,prints and paints
• Easily bonded, formed, nailed and bolted
• Low water absorption
• High chemical resistance
Application of Cast Acrylic Sheet
1. Consumer goods:
sanitary ware, furniture, stationery, handicrafts, basketball board, display shelf, etc.
2. Advertising material:
advertising logo signs, signs, light boxes, signs, signs, etc.
3. Building materials:
sun shade, sound insulation board (sound screen plate), a telephone booth, aquarium, indoor wall sheeting, hotel and residential decoration, lighting, etc.
4. In other areas:
optical instruments, electronic panels, beacon light, car tail lights and various vehicle windshield, etc.
PACKAGING
1.How can i get the best price?
Please provide the product details for your needs so that I can give you the best offer in the first time. Any design and further needs can be communicated to us later in WhatsApp, WeChat, Skype, Mail and other channels. Confirm the price.
2.What are your terms of delivery?
We accept FOB, CIF, EXW, DDU, etc.
3.How can I get the sample?
Sending you samples is ok and no problem.Please inform us of the required size and your contact information, we will send you samples within 1-2 days.
4.What about lead time for mass production?
In fact, this is based on the number of orders.
In general, our production time is 10-14 working days.
TIP: Samples are free for your evaluation! Welcome your inquiry!
